Spirit

  • CNC milled, anodized and sandblasted enclosure
  • Color: Red or Black
  • Dimension: 32x26x14mm, weight: 18g
  • Power supply: 3 - 15V @ 25mA
  • Operating temperature: -10°C to 60°C
  • Fast 32bit ARM processor: 96 DMIPS
  • 6-axis MEMS sensor (rotation to 2000°/s !)
  • Gold plated PCB with Pb-Free soldering
  • 1x native Spektrum connector (2 with adapter)
  • 2x connector for power supply, 4x for servos
  • Smallest, full featured FBL controller in the world

Spirit Pro

  • CNC milled, anodized and sandblasted enclosure
  • Color: Aluminium satin
  • Dimension: 33x32x14mm, weight: 20g
  • Power supply: 3 - 15V @ 25mA
  • Operating temperature: -10°C to 60°C
  • Latest generation, Ultra Fast
    32bit ARM processor: 210 DMIPS
  • MEMS sensor with 9-axis fusion
    (rotation to 2000°/s !)
  • Gold plated PCB with Pb-Free soldering
  • Integrated S-BUS Inverter
  • 2x native Spektrum connectors
  • 3x connector for power supply, 5x for servos

Spirit & Spirit Pro Features

  • Paddle simulation with inexpressible feeling
  • Classic flybar mechanics support
  • Extreme vibration immunity for all helicopter types
  • Spectrum analysis for model diagnostics
  • Flight log with recorded events
  • Easy configuration with setup wizard
  • Bluetooth and Wifi support for Smart devices
  • Integration with Jeti Duplex and FrSky transmitters
  • Available for Windows, OSX, Linux, iOS, Android, WP, Sailfish, FreeBSD, Raspberry Pi and more
  • Stabilisation for scale pilots and beginners
  • Reliable, full-featured rescue system
  • Integrated Bank Switching and Real-Time tuning
  • Governor for Electric, Nitro and Gasser Helicopters
  • BEC tester with load verification
  • Support for PWM, Futaba S-BUS, PPM,
    Spektrum DSM2/DSMX, JETI and FrSky integration,
    SRXL/SUMD/UDI/X-Bus receivers
  • Support for all servo types:
    1520/960/760µs @ 50 - 560Hz
  • Support for CCPM 90/120/135/140°

All features are available for both units and immediately. Updates are free of charge, always!
